性能特點
伺服電機、步進電機(任選) |
Servo motor, stepper motor (optional) |
變頻調(diào)速 |
Frequency Control |
PLC人機界面操作,7”彩色觸摸屏 |
PLC, human-machine interface control,7” touch screen |
氣動銅排熱合 |
Copper sealing bar |
切袋方式為飛刀,飛刀由氣缸或伺服驅(qū)動 |
Cutting by flying knife controlled by servo |
光電跟蹤定長 |
Electro-optical tracking fixed-length |
技術參數(shù)
電源 |
Voltage |
三相四線制 50Hz 380V/220V |
功率消耗 |
Power |
6.5kw |
最大放卷直徑 |
Diameter of unwind |
400mm |
制袋長度 |
Length of making bag |
70-1200mm |
制袋寬度 |
Width of making bag |
400-650mm |
制袋線速度 |
Line speed of machine |
40m/min |
